Home / Products / Downlight / ELLA-Hotel Round Adjustable 5W-35W
Overview Specs

ELLA-Hotel Round Adjustable 5W-35W

ELLA-Hotel Round Adjustable 5W-35W

Products Specification:

Application: Recessed-mounted, Pendant

SDCM: <3

Beam Angle: 15°, 24°, 38°, 55°

Power: 5W, 8W, 10W, 15W, 20W, 25W, 30W, 35W

CCT: 2700K, 3000K, 4000K

Line Drawing:

ELLA-Hotel Round Adjustable 5W-35W

General Features:

Accessories

AVA - Commercial MR16 Modular Downlight 5-15W

AVA - Commercial MR16 Modular Downlight 5-15W

Secondary Reflector




ELLA-Hotel

(Round Adjustable Version)

ELLA Hotel downlight fixtures offer an all-time exceptional performance with an exceptional wide range of options covering 4 sizes, 8 wattages, adjustable/fixed & trim/trimless mounting ring,  round & square shape, single & multiple luminaire combo, 3 reflector colors as well as 2 accessories. All of these versatile packages are realized in the unified classic and aesthetically designed appearance with exceptional light quality.


 ELLA-Hotel Round Adjustable 5W-35W

Atmosphere-boosting Lights

Light is not just a brightness that lets you see things, it sets a mood and creates atmosphere. ELLA Hotel series offers 4 kinds of quality lights-oblique, direct, elliptical, and small round-to set different moods and create different atmospheres. Each of the four options will bring you a unique atmosphere lighted up in a precisely controlled lighting effect.

 ELLA-Hotel Round Adjustable 5W-35W



4 Beam Angles

Available in 15°, 24° , 38° and 55° beam angles, ELLA LED recessed downlight allows enough flexibility for you to choose from narrow beam on small objects requiring accent lighting to flood light on walls lacking general brightness. But no matter which angle is needed and where it is needed, one thing that remains the same is ELLA's high-level light quality and evenly blended light edge.


 ELLA-Hotel Round Adjustable 5W-35W

Above-average Anti-glare

ELLA's thoughtful design enlarges the cut-off angle to be 38°, which helps every user easily get rid of the annoying and damaging glare issue. Therefore, on one hand, ELLA brings a very high level of visual comfort, and on the other hand, it also realizes healthy lighting need, which is crucial especially for families with newborns, school-age children, and family members staring at screens a lot.


 ELLA-Hotel Round Adjustable 5W-35W

Anti-glare Accessories

In order to push the anti-glare effect further to a new level, ELLA is designed to be compatible with either honeycomb or soft lens, so that UGR could be minimized.

ELLA cares about every user's eye health very much.

 ELLA-Hotel Round Adjustable 5W-35W



Super Modular Luminaire

ELLA Hotel series has made itself super modular from inside out. You can easily make a brand new luminaire by a quick and simple twist of the LED module + mounting ring combos: round & square, trim & trimless, fixed & adjustable. All these infinite possibilities will make the luminaire fit right into any commercial, residential, and especially hospitality settings. Therefore, no matter the demanding customer is expecting an LED recessed downlight solution for his hotel, store, restaurant, high-end bathroom, or the sweet home, you can always say yes.


 ELLA-Hotel Round Adjustable 5W-35W

Ultra Easy Installation

ELLA's super modular design helps you wave farewell to the cost- and time-consuming installation work, and ring in the pleasant easy installation. With no tool needed at all, ELLA can be installed and taken out in seconds.

No more annoying dangling downlight fixtures, no more waiting for the electrician, and no more scratching on the fresh-paint ceiling.

Specs

-Elegant & compact in its style, versatile in its using.


-Precise light control, 15°, 24°, 38°, 55° beam lens options.


-Interchangeable different color secondary reflectors for aniti-glare and decorative purpose.


-Super modular design enables no-tool installation/replacement of LED module, mounting ring, beam lens, honeycomb filter, and secondary reflector.


-355° rotation and 30° tilt.


-Anti-glare accessories provide maximum visual comfort.


-IP20 is standard, IP44 is optional.


Order info.PowerLed CurrentLuminous
Flux(lm)
CRICCTBeam Angle
(°)
EM050-EF51RA01-15D5W120mA311 lm90+2700K15°
EM050-EF51RA01-24D5W120mA304 lm90+2700K24°
EM050-EF51RA01-38D5W120mA319 lm90+2700K38°
EM050-EF51RA01-55D5W120mA306 lm90+2700K55°
EM050-EF51RA01-15D8W180mA394 lm90+2700K15°
EM050-EF51RA01-24D8W180mA386 lm90+2700K24°
EM050-EF51RA01-38D8W180mA404 lm90+2700K38°
EM050-EF51RA01-55D8W180mA388 lm90+2700K55°
EM060-EF61RA01-15D10W250mA659 lm90+2700K15°
EM060-EF61RA01-24D10W250mA710 lm90+2700K24°
EM060-EF61RA01-38D10W250mA724 lm90+2700K38°
EM060-EF61RA01-55D10W250mA609 lm90+2700K55°
EM060-EF61RA01-15D15W350mA924 lm90+2700K15°
EM060-EF61RA01-24D15W350mA1000 lm90+2700K24°
EM060-EF61RA01-38D15W350mA1076 lm90+2700K38°
EM060-EF61RA01-55D15W350mA1007 lm90+2700K55°
EM070-EF71RA01-15D20W500mA1224 lm90+2700K15°
EM070-EF71RA01-24D20W500mA1389 lm90+2700K24°
EM070-EF71RA01-38D20W500mA1322 lm90+2700K38°
EM070-EF71RA01-55D20W500mA1159 lm90+2700K55°
EM070-EF71RA01-15D25W600mA1730 lm90+2700K15°
EM070-EF71RA01-24D25W600mA1851 lm90+2700K24°
EM070-EF71RA01-38D25W600mA1761 lm90+2700K38°
EM070-EF71RA01-55D25W600mA1744 lm90+2700K55°
EM090-EF91RA01-15D30W700mA2061 lm90+2700K15°
EM090-EF91RA01-24D30W700mA2171 lm90+2700K24°
EM090-EF91RA01-38D30W700mA2056 lm90+2700K38°
EM090-EF91RA01-55D30W700mA2068 lm90+2700K55°
EM090-EF91RA01-15D35W850mA2463 lm90+2700K15°
EM090-EF91RA01-24D35W850mA2591 lm90+2700K24°
EM090-EF91RA01-38D35W850mA2445 lm90+2700K38°
EM090-EF91RA01-55D35W850mA2472 lm90+2700K55°



ImageDescriptionModel NO#Available for
Ella-HotelHoneycomb FilterEM050-HEM050

 Ella-Hotel

Beam Soft LensEM050-LEM050
Ella-HotelHoneycomb FilterEM060-HEM060
Ella-HotelBeam Soft LensEM060-LEM060
Ella-HotelHoneycomb FilterEM070-HEM070
Ella-HotelBeam Soft LensEM070-LEM070
Ella-HotelHoneycomb FilterEM090-HEM090



Downloads

Model Power Picture Download
EM050 7w Ella hotel 7W EM050 LED Module + Mounting Ring Download
Model Power Picture Download
EM050 7w Ella hotel 7W EM050 LED Module + Mounting Ring Download
Model Power Picture Download
EM050 7w Ella hotel 7W EM050 LED Module + Mounting Ring IESLDT
EM060 9W Ella hotel 9W EM060 LED Module + Mounting Ring IESLDT
EM070 25W Ella hotel 25W EM070 LED Module + Mounting Ring IESLDT
EM090 30W Ella hotel 30W EM090 LED Module + Mounting Ring IESLDT
EM090 35W Ella hotel 35W EM090 LED Module + Mounting Ring IESLDT

How can we support you?

*Subscribe for new products & discount.

YES
NO

COMMENTS

More About The ELLA Family

As the latest generation of ENCORE downlight system, ELLA has not only kept the aesthetic design, precise light control and great UGR, but also has upgraded the versatility to a new level with the super modular design in a compact format. ELLA's LED module matches with numerous mounting rings within the system, offering a wide range of options particularly for hospitality, residential, and any indoor commercial setting. On top of mounting rings, ELLA also provides many possibilities in shape, round or square; adjustment, fixed or adjustable; size and wattages.
